Stationary battery Foton FD12-40Ah

Description

Lead-acid battery (lead-acid or VRLA) Foton® Pro-Cycle® FD12-40, 12V 40Ah - "deep cycle" variant, with increased resistance to deep discharges and high cyclicity. It is mainly used in photovoltaic or wind systems, UPS, building alarms, surveillance systems and in other applications where you need energy backup.

TECHNICAL SPECIFICATION:

Brand: Foton® Pro-Cycle® (Foton and Pro-Cycle are registered trademarks of Sprinter 2000 S.A.)

Technology: AGM VRLA

Uses: energy backup in photovoltaic or wind systems, UPS, alarms, lighting systems, traction and semi-traction (strollers for disabled people, electric vehicles), etc.

Coding: FD12-40

Equivalent/compatible codes: NP38-12 (manufacturers Enersys, Yuasa, Genesis) / FCG12-38 (Caranda) / LC-X1238APG (Panasonic)

Voltage: 12 V

Nominal capacity: 42 Ah / 4.2A 10Hr, at 1.8V/cell, 25°C

Maximum discharge current: 400A (maximum 5 seconds)

Temperature range: discharge -15°C...+50°C / charging -10°C...+50°C / storage -20°C...+50°C

Optimum temperature of use: +25°C ± 3°C

Charging current: Cyclic use: <13.5A, U 14.5V...15V at 25°C. Temperature correction -30mV/°C / Buffer use: <13.5A, U 13.5V...13.8V at 25°C. Temperature correction -18mV.

Influence of temperature on capacity: 102% of capacity at 40°C / 100% of capacity at 25°C / 85% of capacity at 0°C

Self-discharge: 9% after 3 months of storage / 18% after 6 months of storage / 35% after 12 months of storage

Terminal type: FM6, on the long side

Dimensions: 197 x 165 x 170 mm (L x W x H), tolerance ± 2 mm

Weight: 13.5 kg

Warranty: Legal warranty (compliance) 24 months. Commercial warranty (durability) 12 months from the date of purchase. Service requests during the warranty period are submitted here.

 Do not throw in the trash after use - hand it over only to authorized collection centers.
