Portable fan ATEX Z1 Ramfan VF-EFi75 30cm

Description

The Ramfan™ (USA) range of fans, ducts and venturi units for hazardous areas is ATEX and IECEx certified for use in hazardous areas and is available in 115V (on request) or 230 volt versions. They are PORTABLE professional ventilators, intended especially for the fields: interventions in emergency situations (firemen / ISU), petrochemical industry, flour mills and silos, cement factories, interventions in underground utility networks (gas, sewage, water, energy , underground optical fiber), etc.

Ramfan™ is the world's largest manufacturer of fans for hazardous areas.

Professional portable fan VF-EFi75xx (30cm) - with up to 2500 cfm (4250 m3/h), with its durable antistatic PC/ABS housing is weatherproof, fireproof and resistant to chemicals, it is ideal for use in the most difficult environments. Two integrated duct adapters allow the use of a variety of ducts and allow maximum flexibility in fan positioning.

TECHNICAL SPECIFICATION:

Brand and model: Ramfan VF-EFi75xx (30cm, 230VAC)

IMPA code: 591506

Model description: 30 cm professional portable fan for hazardous areas

Protection coding: II 2 G Ex db eb IIB T6 Gb / II 2 G Ex h IIB T6 Gb

Risk zone (gas): Z1 / Zones 1 and 2, Gas Groups IIA and IIB

Temperature class (gas): T6

Operating temperature (gas): -20°C... +40°C

Sealing against water and dust: IP55 (resistant to rain)

Protection type/class: 'db' - fire-resistant housing / 'eb' - increased safety / 'h' - non-electrical equipment

Material: Durable anti-static PC/ABS housing - weatherproof, smudge-proof, v0 fireproof and chemical-resistant

Supply voltage: 230Vac 50/60Hz, power cable 7.6m long

Current (start/work): 27A / 4.4A

Engine: 0.75HP / 0.56kW

Noise level: 89 dB at 1 m distance

Airflow: Free air through duct 2,500 cfm (4,250 m3/h) / through 4.6m duct with a 90° angle 1,664 cfm (2,829 m3/h)

Dimensions: 41 x 38 x 41 cm

Pipe adapters: 2

Pipe included: 4.6m

Container: Not included with this model

Certificates: DEMKO 09 ATEX 0926969X / IECEx UL 13.0062X

Weight: 20 kg
