Solar accumulator Enersys PowerSafe SBS XC 150F-FT

Description

Made in France!

The EnerSys® PowerSafe® SBS® XC range of lead-acid cells and monoblocks with regulating valve is designed to meet the challenging requirements of grid and renewable energy applications.

PowerSafe SBS XC benefits from EnerSys' state-of-the-art Thin Plate Pure Lead (TPPL) technology platform. The fast recharging and high cyclic performance of PowerSafe SBS XC make it the perfect solution for difficult operating conditions in poor network environments, where there is a high risk of uncontrolled partial state of charge (PSoC) operation. It has the advantage of resistance against deep discharges.

The high cyclicality of PowerSafe SBS XC and its ability to operate in uncontrolled PSoC conditions, where the ambient temperature can often be high, offers the operator significant benefits in terms of total cost of investment (TCO).

The key benefits are:

• Designed to be used in unreliable grid and renewable energy applications
• Wide range of ampere-hours: 92 to 1870 Ah
• Including 2V DIN size cells and 12V front terminal blocks
• Excellent cyclic performance
• Exceptional ability to accept fast charging
• Recovery from deep discharge
• Resistance to harsh environments
• TPPL technology – high energy density
• Storage period of up to 2 years (reduced self-discharge)
• Low total cost of ownership
• Monoblocs and cells can be installed in cabinets or on stands, close to the place of use. A separate room for batteries is not required

PRODUCT SPECIFICATION:

Brand/manufacturer: EnerSys

Battery range: PowerSafe SBS XC - the range intended for the backup of energy from renewable sources (photovoltaic, wind, etc.)

Model: XC 150F-FT

Produced in/Country of origin: France

Classification according to EUROBAT 2015: "Very Long Life" (>12 years projected life span)

Nominal voltage: 12V

Nominal capacity: 151Ah C₁₀/1.80Vpc @ 20°C / 154Ah C₁₂₀/1.85Vpc @ 25°C

Housing: Containers and covers made of fire-resistant ABS material classified UL94 V-0, very resistant to shocks and vibrations

Electrolyte: High quality dilute sulfuric acid absorbed in fiberglass separators (AGM) to prevent leakage in case of accidental damage

Internal resistance: 3.8mΩ

Short circuit current: 3330A

Dimensions: 561 x 125 x 283 mm (LxWxH)

Recommended charging voltage: 2.29Vpc at 20°C (2.27Vpc at 25°C)

Recommended applications: energy storage from renewable sources, UPS, telecommunications, etc.

Operating temperature: -40°C : +50°C

Maximum storage time: up to 24 months at 20°C

Maintenance: no maintenance, no need to add distilled water

Terminals: 2 x M6 M (front terminal)

Handle for transport and handling: Yes

Applicable standards and certifications: IEC 60896-21/22 / IEC 61427-1 / batteries will be installed in accordance with IEC 62485-2 / classified as a leak-free battery that can be transported as non-dangerous goods according to ADR/RID, IMDG and IATA / ISO 9001, ISO 14001 and OHSAS 18001

Weight: 49.0kg

 Batteries contain lead and acid electrolyte - hazardous substances for the environment and health. Do not disassemble, do not throw in fire and do not throw away. Hand over the used batteries to the authorized collectors or to the used car battery collection boxes in the big stores.
