Bidirectional Voltage Regulator Salicru VR-10000-EQX-SLH 10kW

Name: Bidirectional Voltage Regulator Salicru VR-10000-EQX-SLH 10kW
Brand: Salicru
Price: 7319.99 RON
Availability: InStock

RON 7,319^.99 / Buc. (VAT included)

Price alert

Delivery costs are not included

See other options

Bidirectional Voltage Regulator Salicru VR-10000-EQX-SLH 10kW

Bidirectional Voltage Regulator Salicru VR-5000-EQX-SLH 5kW

How can we help?

Ask for details

Description

Salicru - VR EQX

Bidirectional voltage regulators for self-consumption: Solution for voltage problems in photovoltaic installations

The VR EQX voltage regulator range from Salicru - Spain for grid-connected photovoltaic installations prevents interruptions due to over/undervoltage in the supply line. Most regulations governing the connection of this type of system to the grid require that solar inverters shut down if their voltage exceeds certain limits. In unstable grids, this causes unwanted shutdowns in the photovoltaic installation, with consequent loss of energy production and a decrease in the useful life of the solar inverters.

Since, in the vast majority of cases, the surplus energy generated is injected into the grid (in exchange for compensation), traditional unidirectional voltage stabilizers are unsuitable as they cannot carry reverse current. Given that this constitutes a violation of regulations and exposes the loads to serious danger, manipulating the inverter is not a viable solution to the problem either.

These regulators record and manage the grid voltage at all times, responding with fast and precise voltage jumps in the short period of time that may be required for the vast majority of national grids.

The wide range of VR EQX models available:

VR EQX SL - undervoltage regulators (230V + 23V), with models of 5000, 6000 and 10000VA/W. Minimum input voltage 172.5V
VR EQX SH - overvoltage regulators (230V - 23V), with models of 5000, 6000 and 10000VA/W. Maximum input voltage 276V
VR EQX SLH - under- and overvoltage regulators (230V ± 23V), with models of 5000, 6000 and 10000VA/W. Minimum input voltage 172.5V and maximum input voltage 276V

PERFORMANCE:

Power factor PF=1
Cost and energy saving
High response speed
Natural cooling
Large regulation range ±23V
Compact dimensions and wall mounting possible.

Fast response. Stabilization of mains voltage.

Electronic management ensures a rapid response to unwanted variations in the network voltage, establishing an immediate and quality energy supply.
The network to which we connect our self-consumption installations can suffer under- or overvoltage supply fluctuations. These fluctuations are usually more acute at the ends of the line or in the vicinity of generating stations or distribution transformers.

Inverter in an unstable grid without VR EQX versus in a grid with VR EQX:

Current standards state that in the event of a grid voltage outside the limits, self-consumption systems must disconnect. Therefore, if our inverter detects such an anomaly, it will automatically stop generating, regardless of the quality of the solar radiation.

To ensure continuity of generation and, consequently, to avoid financial losses derived from shutdowns of the self-consumption system, VR EQUINOX provides optimal voltage quality to your equipment to keep it fully operational. In addition, its bidirectional capabilities ensure an optimal power surplus to the grid.

Network without VR EQX:

VERSUS with VR EQX:

Compatibility:

VR EQX are compatible with all brands and models of inverters on the market (correlate the inverter model with the VR EQX model - in terms of voltage and power)

TECHNICAL SPECIFICATION:

Brand/Manufacturer: Salicru - Spain (Barcelona). Sprinter2000 is a direct importer and representative in Romania for Salicru Spain

Product country of origin: Spain

Product type: Bidirectional voltage regulator for self-consumption

Range and model: VR EQX SLH (for under and over-voltage) - model VR-10000-EQX-SLH

Manufacturer code: 6B2ST000042 / EAN 8436584874928

Format: Compact

System power: 10000W / 10000VA (10kW / 10 kVA)

Input - Minimum compensation voltage: 172.5V

Operation - Minimum limited voltage RD244/2019: 195.5V

Input - Maximum compensation voltage: 276 V

Operation - Maximum limited voltage RD244/2019: 253V

Frequency: (input): 50 Hz

Input protection: 1-pole circuit breaker

Nominal voltage output voltage and output frequency: 230V 50Hz

Admissible voltage variation: ±23V

Response time: <100ms

Maximum total harmonic distortion (THDv): Zero

Performance: >97%

Margin over nominal: -25% / -20%

Power factor: PF = 1

Operating temperature: -10°C... +50°C

Relative humidity: up to 95% non-condensing

Number of transformers: 1 unit

Maximum altitude: 2400 m above sea level

Protection degree/water and dust tightness: IP20

Cooling: natural

Self-noise level: <25 dB at 1 meter distance

Installation possibilities: Indoor or outdoor / wall mount

Standards: IEC 62103 safety / Electromagnetic compatibility (EMC) EN 61000-6-4; EN-6100-6-2 / Manufacturer certifications ISO 9001, ISO 14001, ISO 45001

Weight: ~48 kg

Dimensions: 250 x 361 x 444 mm

Commercial warranty for individuals: 24 months from the date of purchase.
