Accumulator 4/5 SC 1.2V 2000mAh with blades

Description

NiMH cells model 4/5 CS (or 4/5 Sub C) of 1.2V and 2000mAh, used in various assemblies in medical equipment, electric tools or measuring devices. It comes with spot-welded nickel blades, so you can assemble them easily. Optionally, we can also make various assemblies according to the customer's specification. In this case request the offer.

PRODUCT SPECIFICATION:

Brand: BYD / JJJ

Country of origin: China

Type: NiMH High Power

Manufacturer coding: 4/5 CS, 4/5 SC (Sub C) or 4/5SC2000P-BL, H-4/5SC1500P

Nominal voltage: 1.2V

Nominal capacity: 2000mAh

Number of cycles: over 500 cycles according to IEC61951-2

Charging: standard 200mA x 15 hours

Terminals: Delivered with spot-welded Nickel blades (can be cut by the user if not needed)

Dimensions: L=32.5 ± 0.5 mm, diameter = 22 ± 0.1 mm; Nickel blades with a width of 6.5 mm.

Weight: 41 grams

Packaging: Bulk (industrial packaging, in trays with 20 cells. Price and sale are per piece.

The assembly of the cells in various assemblies will be done only by qualified personnel!

 Warnings: Do not disassemble, do not throw in fire, do not throw in the trash. Hand in used batteries only at authorized collection centers or in the collection bins in large stores.
